6-Strand Wire Rope
TJ Steel Rope's 6-strand range covers the 6×19 and 6×36 line-contact classes — the general-purpose constructions, including 6×19S, 6×25Fi and the Warrington-Seale 6×26WS and 6×36WS — alongside the compacted 6×K31 and 6×K36 classes. Compacted ropes are available with a standard steel core, a plastic-injected core (EPIWRC) that distributes internal pressure and retains core lubricant, or a parallel-lay core (PWRC) built for higher breaking force and shock-load resistance. Diameters run from 10mm to 80mm in IWRC or fiber core.
Choosing within the 6-strand range
Line contact or compacted?
The 6×19 and 6×36 classes are line-contact ropes — the general-purpose workhorses, where 6×19 resists abrasion and 6×36 resists fatigue. The 6×K31 and 6×K36 classes are compacted: the strands are rolled after stranding, which raises breaking force at the same diameter and spreads pressure on drums and sheaves. Compacted costs more and lasts longer.
About TJ Steel Rope
Made in Nantong since 1987
Four decades of rope-making in one factory. 33,000 m², 65 machines, 30,000 tons a year to EN 12385, ASTM A1023 and GB/T standards — with around 4,000 tons of finished rope in stock. OEM supplier to China's leading crane manufacturers.
Need a diameter or grade not listed? We manufacture 10–80 mm to your specification.
